کوپلند سری َKAA / KAT / KAL آمریکا و یک و نیم اسب و بالا تر انگلستان DLE / DLSG / DLL

جهت سفارش قطعه مورد نظر شماره قطعه را ار روی نقشه کمپرسور بررسی و برای شرکت ما ارسال نمائید

1- END COVER GASKET
2- BOTTOM PLATE O-RING
3- BOTTOM PLATE GASKET
4- SIGHT GLASS GASKET - NEOPRENE, (2 per Compressor)
5- SIGHT GLASS, DIAMETER 1-1/32", THICKNESS 13/32"
6- SERVICE VALVE GASKET
7- SUCTION STRAINER SCREEN, FLANGE O.D. 11/16", LENGTH 1-5/16"
8- MAIN BUSHING INSERT, 2 USED PER COMPRESSOR ROUGH BORE
8- MAIN BUSHING INSERT, 2 USED PER COMPRESSOR
9- END BUSHING INSERT, 1 USED PER COMPRESSOR (THIN WALL)
9- END BUSHING INSERT, 1 USED PER COMPRESSOR ROUGH BORE
9- END BUSHING INSERT, 1 USED PER COMPRESSOR
10- CRANKSHAFT 0.5 - 1.5 Hp
10- CRANKSHAFT 1.0 Hp
10- CRANKSHAFT 0.5 - 1.5 Hp - WITH OIL PUMP SLOT
10- CRANKSHAFT 1.0 Hp - WITH OIL PUMP SLOT
11- CRANKSHAFT PLUG
12- PISTON AND ROD ASSEMBLY, refer individual items
13- PISTON, 1-9/16" BORE, 1/2" WRIST PIN
13- PISTON, 1-11/16" BORE, 5/8" WRIST PIN
13- PISTON, 1-7/8" BORE, 5/8" WRIST PIN
13- PISTON, 1-7/8" BORE, 1/2" WRIST PIN
13- PISTON, 1-7/8" BORE, 1/2" WRIST PIN
13- PISTON, 1-7/8" BORE, 5/8" WRIST PIN
13- PISTON, 1-7/16" BORE, 1/2" WRIST PIN
13- PISTON, 1-1/2" BORE, 1/2" WRIST PIN
14- CONNECTING ROD, 1/2" WRIST PIN
14- CONNECTING ROD, .010" UNDERSIZE, 1/2" WRIST PIN
14- CONNECTING ROD, .020" UNDERSIZE, 1/2" WRIST PIN
14- CONNECTING ROD, 5/8" WRIST PIN
14 CONNECTING ROD, .010" UNDERSIZE, 5/8" WRIST PIN
14- CONNECTING ROD, .020" UNDERSIZE, 5/8" WRIST PIN
14 CONNECTING ROD, 1/2" WRIST PIN
14- CONNECTING ROD, .010" UNDERSIZE, 1/2" WRIST PIN
14 CONNECTING ROD, .020" UNDERSIZE, 1/2" WRIST PIN
14- CONNECTING ROD, 5/8" WRIST PIN
14 CONNECTING ROD, .010" UNDERSIZE, 5/8" WRIST PIN
14- CONNECTING ROD, .020" UNDERSIZE, 5/8" WRIST PIN
15 OIL PUMP ASSEMBLY, ALUMINUM
16- BEARING HOUSING GASKET, (WITHOUT PUMP)
16- PUMP HOUSING GASKET
17- O-RING FOR PICKUP TUBE
18- OIL PUMP PICKUP TUBE
19- BEARING COVER PLATE GASKET
19- OIL PUMP COVER GASKET
20- VALVE PLATE ASSEMBLY
21- DISCHARGE AND SUCTION VALVE REED PINS,EXCEPT 2-15/16" BORE
22- SUCTION VALVE REED SHORT
22- SUCTION VALVE REED
23- CRIMP PAD
24- VALVE PLATE GASKET, 1-1/2" BORE
24- VALVE PLATE GASKET, 1-7/8" BORE
25- VALVE PLATE PIN
26- DISCHARGE VALVE REED
27- VALVE PLATE SUPPORT
28- HEAD GASKET
29- TERMINAL O-RING
30- TERMINAL HERMETIC
31- TERMINAL KIT
32- TERMINAL BOARD INSULATOR
33- TERMINAL BOLT
34- TERMINAL NUT, BRASS, CONTROL CIRCUIT
35- TERMINAL WASHER, STEEL
36- TERMINAL WASHER, FIBER
37- TERMINAL SEAL
38- TERMINAL INSULATOR, FIBER
39- CRANKSHAFT SPACER
